Functional Inks and More

Screen printing inks

Product

Description

Curing

Benefit

Technical information

Bectron®
CP 6662
Conductive silver ink10 min at 120°COptimized for fine line printing, very flexible, long screen open time, good adhesion to untreated and treated PET films,
<0.010 Ω/sq/mil

PDF (EN)
PDF (DE)

Bectron®
CP 6663
Conductive silver ink10 min at 120°COptimized for membrane switches,
<0.015 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
CP 6666
Conductive silver ink10 min at 120°CGood adhesion to glass,
<0.025 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
CP 6668
Conductive silver ink3 min at 120°CVery fast curing version,
<0.010 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
CP 6669
Conductive silver ink5 min at 120°CFast curing version optimized for a long screen open time,
<0.010 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
CP 6671
UV-curable conductive silver ink5 m/min at
>700 mJ/cm² UVA and 2 min at 100°C
UV-curable and ultra-low VOC, superior screen open time,
<0.030 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
CP 6680
Thermoformable conductive silver ink10 min at 120°COptimized for in-mold electronics,
<0.025 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
CP 6681
Conductive silver ink10 min at 120°COptimized for PC films,
<0.015 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
CP 6690
High temperature conductive silver ink10 min at 160°COptimized for high temperature applications up to 200°C, good adhesion to ELAN-Film HT 180 and Kapton
<0.015 Ω/sq/mil
PDF (EN)
PDF (DE)

Product

Description

Curing

Benefit

Technical information

Bectron®
GP 9552
Conductive carbon ink10 min at 120°CSilver top-coat with good adhesion to treated PET films,
<40 Ω/sq/mil


PDF (EN)
PDF (DE)

Bectron®
GP 9553
Conductive carbon ink10 min at 120°CGood adhesion to silver and untreated PET films,
<40 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
GP 9555
Conductive carbon ink10 min at 120°CGood adhesion to glass,
<50 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
GP 9580
Thermoformable conductive carbon ink 10 min at 120°COptimized for in-mold electronics, good adhesion to silver and PC films,
<55 Ω/sq/mil
PDF (EN)
PDF (DE)

Product

Description

Curing

Benefit

Technical information

Bectron®
CP 6611
Conductive silver/carbon ink10 min at 120°CLong screen open time,
<0.025 Ω/sq/mil

PDF (EN)
PDF (DE)
Bectron®
CP 6651
Conductive silver coated copper ink10 min at 120°COptimized for EMI shielding,
<1 Ω/sq/mil

PDF (EN)
PDF (DE)

Product

Description

Curing

Benefit

Technical information

Bectron®
DP 8442
Insulating ink green5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
PDF (DE)
Bectron®
DP 8443
Insulating ink blue5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
PDF (DE)
Bectron®
DP 8444
Insulating ink colorless5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
PDF (DE)
Bectron®
DP 8490
High temperature insulating ink10 min at 160°COptimized for high temperature applications up to 200°C, good adhesion to ELAN-Film HT 180 and KaptonPDF (EN)
PDF (DE)

Product

Description

Curing

Benefit

Technical information

Bectron®
CP 6662
Conductive silver ink10 min at 120°COptimized for fine line printing, very flexible, long screen open time, good adhesion to untreated and treated PET films,
<0.010 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
CP 6668
Conductive silver ink3 min at 120°CVery fast curing version,
<0.010 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
CP 6669
Conductive silver ink5 min at 120°CFast curing version optimized for a long screen open time,
<0.010 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
DP 8442
Insulating ink green5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
PDF (DE)
Bectron®
DP 8443
Insulating ink blue5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
PDF (DE)
Bectron®
DP 8444
Insulating ink colorless5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
PDF (DE)

Product

Description

Curing

Benefit

Technical information

Bectron®
CP 6680
Thermoformable conductive silver ink10 min at 120°COptimized for in-mold electronics,
<0.025 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
CP 6681
Conductive silver ink10 min at 120°COptimized for PC films,
<0.015 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
GP 9580
Thermoformable conductive carbon ink 10 min at 120°COptimized for in-mold electronics, good adhesion to silver and PC films,
<55 Ω/sq/mil
PDF (EN)
PDF (DE)

Product

Description

Curing

Benefit

Technical information

Bectron®
CP 6690
High temperature conductive silver ink10 min at 160°COptimized for high temperature applications up to 200°C, good adhesion to ELAN-Film HT 180 and Kapton
<0.015 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
DP 8490
High temperature insulating ink10 min at 160°COptimized for high temperature applications up to 200°C, good adhesion to ELAN-Film HT 180 and KaptonPDF (EN)
PDF (DE)

Product

Description

Curing

Benefit

Technical information

Bectron®
CP 6671
UV-curable conductive silver ink5 m/min at >700 mJ/cm² UVA and 2 min at 100°CUV-curable and ultra-low VOC, superior screen open time,
<0.030 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
DP 8442
Insulating ink green5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
PDF (DE)
Bectron®
DP 8443
Insulating ink blue5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
PDF (DE)
Bectron®
DP 8444
Insulating ink colorless5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
PDF (DE)

Product

Description

Curing

Benefit

Technical information

Bectron®
CP 6662
Conductive silver ink10 min at 120°COptimized for fine line printing, very flexible, long screen open time, good adhesion to untreated and treated PET films,
<0.010 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
CP 6611
Conductive silver/carbon ink10 min at 120°CLong screen open time,
<0.025 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
GP 9552
Conductive carbon ink10 min at 120°CSilver top-coat with good adhesion to treated PET films,
<40 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
GP 9553
Conductive carbon ink10 min at 120°CGood adhesion to silver and untreated PET films,
<40 Ω/sq/mil
PDF (EN)
PDF (DE)
Bectron®
DP 8442
Insulating ink green5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
PDF (DE)
Bectron®
DP 8443
Insulating ink blue5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
PDF (DE)
Bectron®
DP 8444
Insulating ink colorless5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
PDF (DE)

Product

Description

Curing

Benefit

Technical information

Bectron®
EL 7001 AB
Active phosphor
blue ink
5 m/min at >600 mJ/cm² UVAPEDOT, paper and various films like PET or PCPDF (EN)
PDF (DE)
Bectron®
EL 7002 AC
Active phosphor
cyan ink
5 m/min at >600 mJ/cm² UVAPEDOT, paper and various films like PET or PC

PDF (EN)
PDF (DE)

Bectron®
EL 7003 AG
Active phosphor
green ink
5 m/min at >600 mJ/cm² UVAPEDOT, paper and various films like PET or PCPDF (EN)
PDF (DE)
Bectron®
EL 7030 D
Dielectric ink5 m/min at >600 mJ/cm² UVAPEDOT, paper and various films like PET or PCPDF (EN)
PDF (DE)
Bectron®
EL 7080 TC
Transparent conductive ink5 min at 100°CPaper and various films like PET or PCPDF (EN)
PDF (DE)
Bectron®
EL 7090 E
Encapsulation ink5 m/min at >200 mJ/cm² UVAPEDOT, paper and various films like PET or PCPDF (EN)
PDF (DE)
Bectron®
CP 6662
Conductive silver ink10 min at 120°COptimized for fine line printing, very flexible, long screen open time, good adhesion to untreated and treated PET films,
<0.010 Ω/sq/mil
PDF (EN)
PDF (DE)
