Printed Electronics

We combine the knowhow and the perspectives of chemistry, printing technology and electronics.

ELANTAS develops and manufactures functional pastes, such as silver or carbon inks, as well as insulators and printable dielectrics for screen printing. These can be solvent-based or UV-curable. We place great emphasis on maximum user friendliness, such as good runnability and simple handling. At the same time, we strive to optimize the cost-benefit ratio in the area of the raw materials used and the pigmentation of the ink systems.

Our portfolio includes conductive inks, insulating inks and functional screen-printing inks for applications such as membrane switches, touch surfaces, in-mold electronics, hybrid electronics, sensors, RFID antennas and electroluminescent lighting. Typical applications are in industrial and automotive.

Joining our strengths – ELANTAS Europe and Saralon

With the cooperation of Saralon and ELANTAS in 2023 we extended our product portfolio of functional inks by e.g. copper inks, stretchable inks, electroluminescent inks, conductive adhesive inks and many more.

Do you need further information about our printed electronic products?

Please get in touch with us. We are looking forward to your email to ADVANCEDPRINTING@remove-this.ALTANA.remove-this-also.COM

 REQUEST TECHNICAL PRODUCT DATASHEET

ProductDescriptionCuringBenefit/ Typical propertiesTechnical information
Bectron® CG 5660                         Electronic conductive adhesive (ECA)45 min at 90°C or 10 min at 130°CSingle component, conductive, epoxide, adhesive for applications in electronics and printed electronics, connecting electronic components, screen printable, 0.400 O/sq/milPDF (EN)
Bectron® CG 5661Electronic conductive adhesive (ECA)45 min at 90°C or 10 min at 130°CSingle component, conductive, epoxide, adhesive for applications in electronics and printed electronics, connecting electronic components, dispensable by jetting, 0.400 O/sq/mil
Saral SilverGlue Beta 700Silver conductive adhesive ink1 min - 3 min at 90°C - 120°CEspecially designed anisotropic silver-based glue to electrically interconnect two substrates, heat activated glue, suitable for paper/plastic.
Screen printable; Solvent based; Thermally cured
PDF
Saral SilverGlue Alpha 600Silver conductive adhesive ink5 min - 20 min at 100°C - 150°CSilver based conducting glue for fixing SMD components or PCB on paper/plastic, Low temperature curing (110°C), two components ink, suitable for paper, plastic and glass.
Screen printable; Solvent based; Thermally cured
PDF
Saral SilverGlue Pressure 200Silver conductive adhesive ink1 min - 2 min at 90°C - 120°CEspecially designed anisotropic silver-based glue to electrically interconnect two substrates, pressure activated glue, suitable for paper/plastic.
Screen printable; Solvent based; Thermally cured
PDF
Saral SilverGlue UV 100UV Silver conductive adhesive ink~500 mJ/cm2 Especially designed  for fast curing of SMD components (with bottom contact pads only) on transparent plastic. UV curable silver based conductive adhesive. Cured glue is isotopically conductive.
Screen printable; Solvent based; Thermally cured
PDF
ProductDescriptionCuringBenefit/ Typical propertiesTechnical information
Elan-glue® AC 1611Insulating and transparent electronic adhesiveUV-cure onlySingle component, acrylates, transparent, globe top in thick layerPDF (EN)
Elan-glue® AC 1650Insulating and transparent electronic adhesiveUV-cure onlySingle component, acrylates, transparent, globe top in thick layerPDF (EN)
Elan-glue® EP 5350Insulating electronic adhesiveThermal cure (90–130°C)Single component, epoxide, fixing electronic componentsPDF (EN)
Elan-glue® EP 5611Insulating electronic adhesiveUV + thermal cureSingle component, epoxide, globe top for electronic componentsPDF (EN)
Elan-glue® EP 5620Insulating and transparent electronic adhesiveThermal cure (80–90°C)Single component, epoxide, transparent, globe top in thin layerPDF (EN)
Saral HotMeltGlue 800Insulating and transparent electronic adhesive1 min - 2 min at 90°C - 110°CAn ink that works as a hot melt glue when heated above 100°C. After printing and drying, the printed sheets can be stacked on top of each other, as the glue is not active at room temperature.
Screen printable; Solvent based; Thermally dried
PDF

ProductDescriptionCuringBenefit/ Typical propertiesTechnical information
Bectron® CP 6680Thermoformable conductive silver ink10 min at 120°COptimized for in-mold electronics, 0.025 Ω/sq/milPDF
Bectron® CP 6681Conductive silver ink10 min at 120°COptimized for PC films, 0.015 Ω/sq/milPDF
Bectron® DP 8480Thermoformable insulating ink10 min at 120°COptimized for in-mold electronics, good adhesion to silver and PC filmsPDF
Bectron® GP 9580Thermoformable conductive carbon ink10 min at 120°COptimized for in-mold electronics, good adhesion to silver and PC films, 55 Ω/sq/milPDF
Bectron® CT 6660Thinner Thinner for Bectron® CP 6680, Bectron® CP 6681PDF (EN)
Saral Copper 100BConductive copper ink5 min -10 min at 110°CLow cost, air-curable copper particle based ink with a low sheet resistance (~10 mΩ /sq/25 μm). Suitable for paper and plastic substrates.
Screen printable; Water-based; Thermally dried/cured
PDF
Saral StretchSilver 800Conductive stretchable silver ink10 min at 120°CStretchable silver ink for stretchable electrical connections. Specially designed for bending applications such as TPU or bendable plastics with a good sheet resistance (30 mΩ/sq/25 μm).
Screen printable; Solvent-based; Thermally dried/cured
PDF
ProductDescriptionCuringBenefit/ Typical propertiesTechnical information
Bectron® CP 6690High temperature conductive silver ink10 min at 160°COptimized for high temperature applications up to 200°C, good adhesion to ELAN-Film HT 180 and Kapton & glass, 0.015 Ω/sq/milPDF
Bectron® DP 8491High temperature insulating ink10 min at 160°COptimized for high temperature applications up to 200°C, good adhesion to ELAN-Film HT 180 and KaptonPDF
Saral Copper 100BConductive copper ink5 min -10 min at 110°CLow cost, air-curable copper particle based ink with a low sheet resistance (~10 mΩ /sq/25 μm). Suitable for paper and plastic substrates.
Screen printable; Water-based; Thermally dried/cured
PDF
ProductDescriptionCuringBenefit/ Typical propertiesTechnical information
Bectron® DP 8481Insulating ink transparent5 m/min at >600 mJ/cm² UVAGood adhesion to silver, treated PET and PC filmsPDF
ProductDescriptionCuringBenefit/ Typical propertiesTechnical information
Bectron® DP 8442Insulating ink green5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF
Bectron® DP 8443Insulating ink blue5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF
Bectron® DP 8444Insulating ink colorless5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF
Bectron® DP 8445Insulating ink colorless and flexible5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF
Bectron® DP 8446Insulating ink green and flexible5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF
Bectron® DP 8480Thermoformable insulating ink10 min at 120°COptimized for in-mold electronics, good adhesion to silver and PC filmsPDF
Bectron® DP 8491High temperature insulating ink10 min at 160°COptimized for high temperature applications up to 200°C, good adhesion to ELAN-Film HT 180 and KaptonPDF
ProductDescriptionCuringBenefit/ Typical propertiesTechnical information
Bectron® EL 7030 DDielectric ink5 m/min at >600 mJ/cm² UVAPEDOT, paper and various films like PET or PCPDF
Saral Dielectric 600Dielectric ink1 min - 2 min at 90°C - 150°CBarium Titanate based ink, suitable for paper and plastic substrates, does not dissolve easily by printing other solvent based inks on top of it. Suitable for electroluminescent displays.
Screen printable; Solvent based; Thermally dried
PDF
Saral UVDielectric 700UV dielectric ink~200 mJ/cm2 Barium Titanate based UV curable ink, suitable for paper and plastic substrates, does not dissolve easily by printing other solvent based inks on top of it. Suitable for capacitors printing.
Screen printable; UV curable; Good adhesion
PDF

ProductDescription          Curing     Benefit/ Typical properties             Technical information
Bectron® CP 6662Conductive silver ink10 min at 120°COptimized for membrane switches, very flexible, long screen open time, good adhesion to untreated and treated PET films, 0.010 Ω/sq/milPDF (EN)
Bectron® CP 6663Conductive silver ink10 min at 120°COptimized for membrane switches, 0.015 Ω/sq/milPDF (EN)
Bectron® CP 6666Conductive silver ink10 min at 120°CGood adhesion to glass, 0.025 Ω/sq/milPDF (EN)
Bectron® CP 6667Conductive silver ink10 min at 120°COptimized for printing finer lines, very flexible, long screen open time, good adhesion to untreated and treated PET films, 0.015 Ω/sq/milPDF (EN)
Bectron® CP 6668Conductive silver ink3 min at 120°CVery fast curing version, 0.010 Ω/sq/milPDF (EN)
Bectron® CP 6669Conductive silver ink5 min at 120°CFast curing version optimized for a long screen open time, 0.010 Ω/sq/milPDF (EN)
Bectron® CP 6671UV-curable conductive silver ink5 m/min at >700 mJ/cm² UVA and 2 min at 100°CUV-curable and ultra-low VOC, superior screen open time, 0.030 Ω/sq/milPDF (EN)
Bectron® CP 6680Thermoformable conductive silver ink10 min at 120°COptimized for in-mold electronics, 0.025 Ω/sq/milPDF (EN)
Bectron® CP 6681Conductive silver ink10 min at 120°COptimized for PC films, 0.015 Ω/sq/milPDF (EN)
Bectron® CP 6690High temperature conductive silver ink10 min at 160°COptimized for high temperature applications up to 200°C, good adhesion to ELAN-Film HT 180 and Kapton & glass, 0.015 Ω/sq/milPDF (EN)
Bectron® CT 6660Thinner Thinner for Bectron® CP 6662, Bectron® CP 6668, Bectron® CP 6669, Bectron® CP 6680, Bectron® CP 6681PDF (EN)
Saral Silver 700Conductive silver ink10 min at 120°CMultipurpose silver ink, with high electrical conductivity (7 mΩ/sq/25 μm), for low-cost applications. Suitable for paper and plastic substrates. Screen printable; Solvent based; Thermalyl dried/curedPDF
Saral HSCSilver 600Conductive silver ink10 min at 120°CHigh conducting (8 mΩ/sq/25 μm) silver ink with a very high solid content (86%), specially designed for thick layer printing (e.g. antenna). Suitable for paper and plastic substrates.
Screen printable; Solvent-based; Thermally dried
PDF
Saral UVSilver 800UV-curable conductive silver ink~ 500 mJ/cm2UV curable silver ink, for fast curing processes. Suitable for paper and plastic substrates. A good sheet resistance (60 mΩ/sq/25 μm).
Screen printable; UV curable; Good adhesion
PDF
Saral StretchSilver 500Conductive stretchable silver ink10 min at 120°CStretchable silver ink for stretchable electrical connections, with a good sheet resistance (25 mΩ/sq/25 μm). Suitable for different stretchable substrates (e.g. textile)
Screen printable; Solvent-based; Thermally dried
PDF
Saral StretchSilverH2O 600Conductive stretchable silver ink2 min - 4 min at 120°CStretchable silver ink for stretchable electrical connections. Especially designed for bending applications (e.g. creasing) of paper. A good sheet resistance (20 mΩ/sq/25 μm).
Screen printable; Water-based; Thermally dried
PDF
Saral SilverH2O 600water-based conductive silver ink10 min at 120°CWater based silver ink with moderate electrical conductivity (14 mΩ/sq/25 μm) and good surface wetting.
Screen printable; Water-based; Thermally dried/cured
PDF
Saral StretchSilver 800Conductive stretchable silver ink10 min at 120°CStretchable silver ink for stretchable electrical connections. Specially designed for bending applications such as TPU or bendable plastics with a good sheet resistance (30 mΩ/sq/25 μm).
Screen printable; Solvent-based; Thermally dried/cured
PDF



ProductDescription                CuringBenefit/ Typical properties Technical information
Bectron® GP 9552Conductive carbon ink10 min at 120°CSilver top-coat with good adhesion to treated PET films, 40 Ω/sq/milPDF
Bectron® GP 9553Conductive carbon ink10 min at 120°CGood adhesion to silver and untreated PET films, 40 Ω/sq/milPDF
Bectron® GP 9555Conductive carbon ink10 min at 120°CGood adhesion to glass, resistance adjustable with Bectron AP 2555, 50 Ω/sq/milPDF
Bectron® AP  2555Modifier10 min at 120°CAdditive to rejust the resistivity of Bectron® GP 9555PDF
Bectron® GP 9580Thermoformable conductive carbon ink10 min at 120°COptimized for in-mold electronics, good adhesion to silver and PC films, 55 Ω/sq/milPDF
Saral Carbon 700AConductive Carbon ink10 min at 120°CSolvent based carbon ink with very good adhesion on plastic and paper. A good sheet resistance (30 Ω/sq/25 μm).
Screen printable; Solvent based; Thermally dried
PDF
Saral CarbonH2O 400Conductive carbon ink10 min at 120°CWater based carbon ink with good surface wetting. Especially designed for paper-based electronics. A good sheet resistance (40 Ω/sq/25 μm).
Screen printable; Water based; Termally dried
PDF
Saral ResistorKOhm 100Resistive ink15 sec - 5 min at 90°C - 120°CCarbon based resistive ink to print resistors in kilo ohm range (1.8 kΩ/sq/6 μm). Very low influence of temperature and humidity in resistance.
Screen printable; Solvent based; Thermally dried
PDF
Saral ResistorMOhm 100Resistive ink15 sec - 5 min at 90°C - 120°CCarbon based resistive ink to print resistors in mega ohm range (~2 MΩ/sq/6 μm). Very low influence of temperature and humidity in resistance.
Screen printable; Solvent based; Thermally dried
PDF



ProductDescriptionCuringBenefit/ Typical propertiesTechnical information
Bectron® CP 6612                           Conductive silver/carbon ink                         10 min at 120°C              Long screen open time, 0.025 Ω/sq/mil                     PDF
Bectron® CP 6618Conductive silver/carbon ink3 min at 120°CVery fast curing version, 0.025 Ω/sq/milPDF
Bectron® CP 6619Conductive silver/carbon ink5 min at 120°CFast curing version optimized for a long screen open time, 0.025 Ω/sq/milPDF
Bectron® CT 6660Thinner Thinner for Bectron® CP 6618, Bectron® CP 6619PDF (EN)
Saral ConductingPolymer 700Conductive polymer ink
Transparent conductive ink
30 sec - 5 min at 90°C -120°CTransparent and conducting polymeric ink, suitable for plastic and paper. High conductivity and a slow drying ink.
Screen printable; Water based; Thermlly dried
PDF
Saral Copper 100BConductive copper ink5 min -10 min at 110°CLow cost, air-curable copper particle based ink with a low sheet resistance (~10 mΩ /sq/25 μm). Suitable for paper and plastic substrates.
Screen printable; Water-based; Thermally dried/cured
PDF
Saral ConductingPolymer 600Conductive polymer ink10 sec - 1 min at 70°C -120°CFast drying transparent and conducting polymeric ink, with a moderate electrical conductivity, suitable for paper.
Screen printable; Water based; Thermlly dried
PDF



Product          Description Curing        Benefit/ Typical properties         Technical information
Bectron® CP 6662Conductive silver in10 min at 120°COptimized for membrane switches, very flexible, long screen open time, good adhesion to untreated and treated PET films, 0.010 Ω/sq/milPDF (EN)
Bectron® CT 6660Thinner Thinner for Bectron® CP 6662PDF (EN)
Saral BluePhosphorL 800phosphor blue ink90°C / ~1 minuteBlue color light emitting ink, long working life of the display, suitable for paper, plastic and glass.
Screen printable; Solvent based; Thermally dried
PDF
Saral GreenPhosphorL 800phosphor green  ink90°C / ~1 minuteGreen color light emitting ink, long working life of the display, suitable for paper, plastic and glass.
Screen printable; Solvent based; Thermally dried
PDF
Saral OrangePhosphorL 800phosphor orange  ink90°C / ~1 minuteOrange color light emitting ink, long working life of the display, suitable for paper, plastic and glass.
Screen printable; Solvent based; Thermally dried
PDF
Saral WhitePhosphorL 800phosphor white  ink90°C / ~1 minuteWhite color light emitting ink, long working life of the display, suitable for paper, plastic and glass.
Screen printable; Solvent based; Thermally dried
PDF
Saral Silver 700Conductive silver ink90°C / ~1 minuteMultipurpose silver ink, with high electrical conductivity (7 mΩ/sq/25 μm), for low-cost applications. Suitable for paper and plastic substrates.
Screen printable; Solvent based; Thermally dried/cured
PDF
Saral ConductingPolymer 700Conductive polymer ink
Transparent conductive ink
90°C / ~1 minuteTransparent and conducting polymeric ink, suitable for plastic and paper. High conductivity and a slow drying ink.
Screen printable; Water based; Thermally dried
PDF
Saral ConductingPolymer 600Conductive polymer ink90°C / ~1 minuteFast drying transparent and conducting polymeric ink, with a moderate electrical conductivity, suitable for paper.
Screen printable; Water based; Thermally dried
PDF
SaralEL Display ink set 1EL ink set (solvent based)90°C / ~1 minute

Saral Silver 700
Saral ConductingPolymer 700
Saral BluePhosphorL 800
Saral Dielectric 600

PDF
SaralEL Display ink set 2EL ink set (solvent based)90°C / ~1 minute

Saral Silver 700
Saral ConductingPolymer 600
Saral BluePhosphorL 800
Saral Dielectric 600

PDF
Product                    Description          Curing Benefit/ Typical properties Technical information
Bectron® EL 7001 ABActive phosphor  blue ink5 m/min at >600 mJ/cm² UVAPEDOT, paper and various films like PET or PCPDF
Bectron® EL 7002 ACActive phosphor cyan ink5 m/min at >600 mJ/cm² UVAPEDOT, paper and various films like PET or PCPDF
Bectron® EL 7003 AGActive phosphor  green ink5 m/min at >600 mJ/cm² UVAPEDOT, paper and various films like PET or PCPDF
Bectron® EL 7030 DDielectric ink5 m/min at >600 mJ/cm² UVAPEDOT, paper and various films like PET or PCPDF
Bectron® EL 7080 TCTransparent conductive ink5 min at 100°CPaper and various films like PET or PCPDF
Bectron® EL 7090 EEncapsulation ink5 m/min at >200 mJ/cm² UVAPEDOT, paper and various films like PET or PC; transparent insulation varnishPDF
Saral UVBluePhosphorL 800UV phosphor blue ink~200 mJ/cm2UV curable blue color light emitting ink, long working life of the display, suitable for paper, plastic and glass.
Screen printable; UV curable; No dielectric layer needed
PDF
Saral UVGreenPhosphorL 800UV phosphor green  ink~200 mJ/cm2UV curable green color light emitting ink, long working life of the display, suitable for paper, plastic and glass.
Screen printable; UV curable; No dielectric layer needed
PDF
Saral UVOrangePhosphorL 800UV phosphor orange  ink~200 mJ/cm2UV curable orange color light emitting ink, long working life of the display, suitable for paper, plastic and glass.
Screen printable; UV curable; No dielectric layer needed
PDF
Saral UVWhitePhosphorL 800UV phosphor white  ink~200 mJ/cm2UV curable white color light emitting ink, long working life of the display, suitable for paper, plastic and glass.
Screen printable; UV curable; No dielectric layer needed
PDF
Saral UVSilver 800UV curable conductive silver ink~ 500 mJ/cm2UV curable silver ink, for fast curing processes. Suitable for paper and plastic substrates. A good sheet resistance (60 mΩ/sq/25 μm).
Screen printable; UV curable; Good adhesion
PDF
Saral ConductingPolymer 600Conductive polymer inkroom temperatureFast drying transparent and conducting polymeric ink, with a moderate electrical conductivity, suitable for paper.
Screen printable; Water based; Thermlly dried
PDF
SaralEL Display ink set 3EL ink set (UV) Saral UVSilver 800
Saral ConductingPolymer 600
Saral UVBluePhosphorL 800
PDF



ProductDescriptionCuringBenefit/ Typical propertiesTechnical information
Saral Silver 700Conductive silver ink      90°C / ~1 minute                   Multipurpose silver ink, with high electrical conductivity (7 mΩ/sq/25 μm), for low-cost applications. Suitable for paper and plastic substrates. Screen printable; Solvent based; Thermalyl dried/cured PDF
Saral Silver 700Conductive polymer ink90°C / ~1 minuteTransparent and conducting polymeric ink, suitable for plastic and paper. High conductivity and a slow drying ink.
Screen printable; Water based; Thermlly dried
PDF
Saral ECBlocking 300Electrochromic blocking ink90°C / ~1 minuteA pattern defining layer ink, which defines the image to be visible at the front electrode.
Screen printable; Solvent based; Thermalyl dried
PDF
Saral ECElectrolyte 200Solid electrolyte ink90°C / ~1 minuteA solid electrolyte ink that works as an ionically conducting layer between the front and back electrodes.
Screen printable; Water based; Thermally dried
PDF
SaralEC Display ink setEC Display set90°C / ~1 minuteSaral Silver 700
Saral ConductingPolymer 700
Saral ECBlocking 300
Saral ECElectrolyte 200
PDF

Application Examples

ProductDescriptionCuringBenefit/ Typical propertiesTechnical information
Bectron® CP 6662Conductive silver ink            10 min at 120°C                   Optimized for membrane switches, very flexible, long screen open time, good adhesion to untreated and treated PET films, 0.010 Ω/sq/mil       PDF (EN)
Bectron® CP 6668Conductive silver ink3 min at 120°CVery fast curing version, 0.010 Ω/sq/milPDF (EN)
Bectron® CP 6669Conductive silver ink5 min at 120°CFast curing version optimized for a long screen open time, 0.010 Ω/sq/milPDF (EN)
Bectron® CP 6671UV-curable conductive silver ink5 m/min at >700 mJ/cm² UVA and 2 min at 100°CUV-curable and ultra-low VOC, superior screen open time, 0.030 Ω/sq/milPDF (EN)
Bectron® CP 6681Conductive silver ink10 min at 120°COptimized for PC films, 0.015 Ω/sq/milPDF (EN)
Bectron® DP 8442Insulating ink green5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
Bectron® DP 8443Insulating ink blue5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
Bectron® DP 8444Insulating ink colorless5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
Bectron® DP 8445Insulating ink colorless and flexible5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
Bectron® CT 6660Thinner Thinner for Bectron® CP 6662, Bectron® CP 6668, Bectron® CP 6669, Bectron® CP 6681PDF (EN)
Saral HSCSilver 600Conductive silver ink15 sec - 60 min at 90°C - 150 °CHigh conducting (8 mΩ/sq/25 μm) silver ink with a very high solid content (86%), specially designed for thick layer printing (e.g. antenna).PDF (EN)
ProductDescriptionCuringBenefit/ Typical propertiesTechnical information
Saral Silver 600A                 Conductive silver ink  15 sec - 60 min at 90°C -150°C      Conductive silver ink (<20 mΩ/sq/25 μm), especially designed for printed battery.                PDF
Saral Carbon 700AConductive Carbon ink15 sec - 5 min at 90°C -120°CSolvent based carbon ink with good adhesion (30 Ω/sq/25 μm).PDF
Saral Zinc 700Zinc based anode ink1 min - 2 min at 90°C - 110°CZinc particle-based ink, which works as an anode in the printed battery.PDF
Saral MnO2 800MnO2 based cathode ink1 min - 2 min at 90°C - 110°CManganese dioxide particle-based ink, which works as a cathode in the printed battery.PDF
Saral BatElectrolyte 700Zinc chloride based electrolyte inkno drying needed.The ink comprises zinc chloride electrolyte in viscous water.PDF
Saral BatBarrier 600Cellulose based separator layer ink1 min - 2 min at 90°C - 110°CAn ionically conductive separation layer ink to keep the anode and the cathode separated.PDF
Saral HotMeltGlue 800Insulating and transparent hot melt adhesive ink1 min - 2 min at 90°C - 110°CAn ink that works as a hot melt glue when heated above 100°C. After printing and drying, the printed sheets can be stacked on top of each other, as the glue is not active at room temperature.PDF
Saral Printed Battery ink setPrinted battery ink set Saral Silver 600A
Saral Carbon 700A
Saral Zinc 700
Saral MnO2 800
Saral BatElectrolyte 700
Saral BatBarrier 600
Saral HotMeltGlue 800
PDF
ProductDescriptionCuringBenefit/ Typical propertiesTechnical information
Saral Silver 700      Conductive silver ink                 90°C / ~1 minute Multipurpose silver ink, with high electrical conductivity (7 mΩ/sq/25 μm).                 PDF
Saral ConductingPolymer 700Transparent and conductive polymer ink90°C / ~1 minuteTransparent and conducting polymeric inkPDF
Saral ECBlocking 300Insulating ink90°C / ~1 minuteA pattern defining layer ink, which defines the image to be visible at thePDF
Saral ECElectrolyte 200Solid electrolyte ink90°C / ~1 minuteA solid electrolyte ink that works as an ionically conducting layer between the front and back electrodes.PDF
SaralEC Display ink setEC Display set    90°C / ~1 minuteSaral Silver 700
Saral ConductingPolymer 700
Saral ECBlocking 300
Saral ECElectrolyte 200
PDF



ProductDescription

Curing

Benefit/ Typical propertiesTechnical information
Bectron® CP 6680Thermoformable conductive silver ink10 min at 120°COptimized for in-mold electronics, 0.025 Ω/sq/milPDF (EN)
Bectron® CT 6660Thinner Thinner for Bectron® CP 6680PDF (EN)
Bectron® CP 6690High temperature conductive silver ink10 min at 160°COptimized for high temperature applications up to 200°C, good adhesion to ELAN-Film HT 180 and Kapton & glass, 0.015 Ω/sq/milPDF (EN)
Saral Heating 100Carbon based heating element ink15 sec - 5 min at 90°C -120°C

 Suitable for a maximum heating temperature of 100°C.



PDF



Product Description Curing Benefit/ Typical properties

Technical information

Bectron® CP 6667Conductive silver ink10 min at 120°COptimized for printing finer lines, very flexible, long screen open time, good adhesion to untreated and treated PET films, 0.015 Ω/sq/milPDF (EN)
Bectron® CP 6500Conductive silver ink10 min at 120°COptimized for printing fine lines, very flexible, long screen open time, good adhesion to untreated and treated PET films, 0.015 Ω/sq/milPDF (EN)
Product Description Curing Benefit/ Typical properties Technical information
Bectron® CP 6690High temperature conductive silver ink10 min at 160°COptimized for high temperature applications up to 200°C, good adhesion to ELAN-Film HT 180 and Kapton & glass, 0.015 Ω/sq/milPDF (EN)
Bectron® DP 8491High temperature insulating ink10 min at 160°COptimized for high temperature applications up to 200°C, good adhesion to ELAN-Film HT 180 and KaptonPDF (EN)
Saral Copper 100BConductive copper ink5 min at 120°CLow cost, air-curable copper particle based ink with a low sheet resistance (~10 mΩ /sq/25 μm).PDF



Product Description Curing Benefit/ Typical properties Technical information
Bectron® CP 6680Thermoformable conductive silver ink10 min at 120°COptimized for in-mold electronics, 0.025 Ω/sq/milPDF (EN)
Bectron® CP 6681Conductive silver ink10 min at 120°COptimized for PC films, 0.015 Ω/sq/milPDF (EN)
Bectron® DP 8480Thermoformable insulating ink10 min at 120°COptimized for in-mold electronics, good adhesion to silver and PC filmsPDF (EN)
Bectron® GP 9580Thermoformable conductive carbon ink10 min at 120°COptimized for in-mold electronics, good adhesion to silver and PC films, 55 Ω/sq/milPDF (EN)
Bectron® CT 6660Thinner Thinner for Bectron® CP 6680, Bectron® CP 6681PDF (EN)
Saral Copper 100BConductive copper ink5 min at 120°CLow cost, air-curable copper particle based ink with a low sheet resistance (~10 mΩ /sq/25 μm).PDF
Saral StretchSilver 800Conductive stretchable silver ink10 min at 120°C

Stretchable silver ink for stretchable electrical connections. Specially designed for bending applications such as TPU or bendable plastics with a good sheet resistance (30 mΩ/sq/25 μm).

PDF
Product Description Curing   Benefit/ Typical properties Technical information
Bectron® CP 6612Conductive silver/carbon ink10 min at 120°CLong screen open time, 0.030 Ω/sq/milPDF (EN)
Bectron® CP 6618Conductive silver/carbon ink3 min at 120°CVery fast curing version, 0.025 Ω/sq/milPDF (EN)
Bectron® CP 6619Conductive silver/carbon ink5 min at 120°CFast curing version optimized for a long screen open time, 0.025 Ω/sq/milPDF (EN)
Bectron® CP 6662Conductive silver ink10 min at 120°COptimized for membrane switches, very flexible, long screen open time, good adhesion to untreated and treated PET films, 0.010 Ω/sq/milPDF (EN)
Bectron® DP 8442Insulating ink green5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
Bectron® DP 8443Insulating ink blue5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
Bectron® DP 8444Insulating ink colorless5 m/min at >600 mJ/cm² UVAGood adhesion to silver, untreated and treated PET filmsPDF (EN)
Bectron® GP 9552Conductive carbon ink10 min at 120°CSilver top-coat with good adhesion to treated PET films, 40 Ω/sq/milPDF (EN)
Bectron® GP 9553Conductive carbon ink10 min at 120°CGood adhesion to silver and untreated PET films, 40 Ω/sq/milPDF (EN)
Bectron® CT 6660Thinner Thinner for Bectron® CP 6612, Bectron® CP 6618, Bectron® CP 6619, Bectron® CP 6662PDF (EN)



Product Description CuringBenefit/ Typical properties Technical information
Bectron® CP 6669Conductive silver ink5 min at 120°CFast curing version optimized for a long screen open time, 0.010 Ω/sq/milPDF (EN)
Bectron® GP 9552Conductive carbon ink10 min at 120°CSilver top-coat with good adhesion to treated PET films, 40 Ω/sq/mil
Screen printable; Solvent based; Thermally dried
PDF (EN)
Saral HumiditySensor 400Carbon based ink5 min - 15 min at 100°C - 120°CFast drying humidity sensitive ink, resistance increases with humidity.PDF
Saral TemperatureSensor 100Carbon based ink5 min - 15 min at 100°C - 120°CFast drying temperature sensitive ink. Resistance increases with temperature.PDF
Saral PressureSensor 200 Carbon based ink10 min - 60 min at 120°CPiezoresistive pressure sensor ink, resistance decreases by increasing pressurePDF



Product Description Curing Benefit/ Typical properties Technical information
Bectron® CP 6612 RConductive silver/carbon ink10 min at 120°CLong screen open time, 0.030 Ω/sq/mil, developed for rotatory printing, for flexible solar cellsPDF (EN)

Messen & Veranstaltungen
